Rotary Tablet Press Machine Matrix
Standardized engineering parameters across single-sided and double-sided rotary tablet compression models available for factory-direct indenting.
| Model Class | Stations | Tooling Type | Max Main Pressure | Pre-Compression | Max Output (tab/h) | Motor Power | Rejection Mechanism |
|---|---|---|---|---|---|---|---|
| BTI-ZP-17 | 17 Stations | EU D / TSM D | 80 kN | 20 kN | 45,000 | 5.5 kW Siemens VFD | Pneumatic Single Reject |
| BTI-ZP-27 | 27 Stations | EU B / TSM B | 80 kN | 20 kN | 120,000 | 7.5 kW Siemens VFD | High-Speed Air Solenoid |
| BTI-ZP-35 | 35 Stations | EU B / BB Tooling | 100 kN | 25 kN | 180,000 | 9.0 kW Siemens VFD | Individual Chute Gate |
| BTI-ZP-45D | 45 Stations (Double) | EU B / BB Tooling | 100 kN | 30 kN | 240,000 | 11.0 kW Siemens VFD | Dual-Chute Air Rejector |
| BTI-ZP-55D | 55 Stations (Double) | EU BB Tooling | 100 kN | 30 kN | 300,000 | 15.0 kW Siemens VFD | Automated Fast Gate |
Automatic Capsule Filling Machine Matrix (NJP Series)
High-precision tamping pin dosing systems for hard gelatin and HPMC capsules with precision powder, pellet, and combination dosing.
| Model | Rated Output | Capsule Formats | Dosing Principle | Filling Accuracy | Vacuum Consumption | Segment Turret |
|---|---|---|---|---|---|---|
| NJP-800 | 48,000 caps/h | 00#, 0#, 1#, 2#, 3#, 4#, 5# | 5-Stage Tamping Pin | ≥ 99.5% (±1%) | 40 m³/h @ -0.08 MPa | Fully Enclosed 10-Station |
| NJP-1200 | 72,000 caps/h | 000#, 00#, 0#, 1#, 2#, 3#, 4# | 5-Stage Tamping Pin + Pellet Doser | ≥ 99.5% (±1%) | 60 m³/h @ -0.08 MPa | Oil-Free Lubricated Cam Indexer |
| NJP-2000 | 120,000 caps/h | 00#, 0#, 1#, 2#, 3#, 4# | Modular Powder / Micro-Pellet | ≥ 99.7% (±0.8%) | 90 m³/h @ -0.09 MPa | Precision Dual Row Segments |
| NJP-3800 | 228,000 caps/h | 00#, 0#, 1#, 2#, 3# | Dual Tamping Disk / Multi-Dose | ≥ 99.7% (±0.8%) | 140 m³/h @ -0.09 MPa | High-Speed Industrial Indexer |
Certified SS 316L Metallurgy & Sanitary Fabrication Standards
To ensure 100% compliance with DRAP regulations, WHO TRS 986, and international pharmacopeias, all solid dosage machinery provided by BTI adheres to verified sanitary construction:
AISI 316L Contact Parts
Powder hoppers, force feeder bowls, discharge chutes, and capsule dosing discs forged exclusively from AISI 316L (EN 1.4404) with certified 3.1 mill test logs.
Ra ≤ 0.4 μm Mirror Polish
All powder contact surfaces electro-polished to mirror finish Ra ≤ 0.4 μm (15 μ-in) to eliminate cross-contamination and prevent powder adherence.
Anti-Wear Turret Coatings
Tablet press turrets treated with Titanium Carbonitride (TiCN) or electroless nickel-phosphorus hardening, extending die pocket longevity under high tonnage.
Passivation & Weld Logs
All sanitary weld seams inspected via video boroscopy and chemically passivated per ASTM A967 with full certification supplied in the turnover package.
BTI Direct Factory Indenting vs. Traditional Local Stockists
Comparing BTI's direct manufacturer indenting model against local Pakistani machine importers and stockists.
| Evaluation Parameter | BTI Factory Direct Indenting | Traditional Local Stockists |
|---|---|---|
| 1. Capital Expenditure (Capex) | Direct Ex-Works (EXW) OEM price eliminating middleman markups (30%–50% savings) | Heavily inflated showroom retail prices with hidden inventory carrying margins |
| 2. Custom Engineering & Tooling | Custom engineered to client URS, exact tooling geometry (EU D/B, multi-tip, embossed) | Rigid shelf stock with generic tooling and obsolete PLC software versions |
| 3. Metallurgy & Sanitary Finish | Certified SS 316L Contact (Ra ≤ 0.4 μm) with 3.1 mill test certificates & passivation logs | Unverified metallurgy; frequent substitution of lower SS 304 or inferior cladding |
| 4. Pre-Shipment Inspection (FAT) | High-resolution FAT video, dry/wet running trials, tooling speed tests before export | Zero pre-shipment FAT logs; buyer accepts whatever machine is delivered from storage |
| 5. Regulatory Compliance (DRAP / cGMP) | Complete turnkey DQ, IQ, OQ, PQ packages and 21 CFR Part 11 audit trails | Generic operator manual only; no qualification dossiers for DRAP licensing |
| 6. Local SAT & Engineering Accountability | On-site Site Acceptance Test (SAT) by certified local field engineers and OEM specialists | Drop-off delivery only; plant owner left to hire unaffiliated third-party technicians |
Serving Pakistan's Major Pharmaceutical Manufacturing Zones
Lahore Pharma Corridor
Headquarters in DHA Phase 5. Active client installations across Sundar Industrial Estate (SIE), Kot Lakhpat, Multan Road, and Ferozepur Road pharma clusters.
Karachi Maritime Hub
Branch office in Memon CHS. Rapid deployment to Korangi Industrial Area, SITE Karachi, Federal B Area, Port Qasim, and Hub Baluchistan.
Hattar Industrial Zone
Dedicated field engineers supporting Hattar Industrial Estate (HIE), Haripur, Peshawar, and northern pharmaceutical production facilities.
Islamabad / Rawalpindi
Continuous coordination with DRAP headquarters and turnkey execution in I-9, I-10, and Kahuta Industrial Triangle.
Solid Dosage Machinery Procurement FAQ
What capacities and tooling standards are available for rotary tablet presses in Pakistan?
What are the dosing accuracy and capsule size capabilities of NJP capsule fillers?
How does BTI guarantee AISI 316L metallurgy and surface finish compliance?
What is the capex difference between factory-direct indenting and local stockist procurement?
How does BTI handle DRAP licensing and cGMP computerized validation?
Ready to Optimize Your Solid Dosage Manufacturing Line?
Submit your target tablet shapes, capsule formats, and hourly output requirements. Our technical procurement engineering desk delivers itemized factory EXW proposals and landed cost estimates within 48 hours.
